Customization Services

Popular trust
Economy is more affordable
1
Requirements
Analysis
Precisely define purity indicators for semiconductor/ photovoltaic/ display panel applications and build customized demand models for clients.
2
Joint
R&D
Collaborate with CNAS-accredited laboratories and university research platforms to optimize formulations and achieve rapid production line conversion.

3
Sample
Verification
Provide small-batch samples and authoritative test reports to ensure performance fully matches customer requirements.
4
Mass Production
and Delivery
After locking in process parameters, launch a multi-thousand-ton production line to guarantee both delivery time and quality meet standards.
Service Highlights

  • 01
    Purity Customization
    Covering a gradient of purity levels from ppb to 99.999%, meeting the stringent requirements of chips smaller than 14nm.
  • 02
    Research-Backed
    176 patents and joint laboratories with universities establish our leading technological position in the industry.
  • 03
    Global Reach
    Supporting rapid sample delivery worldwide, with accompanying test reports to reduce customer decision-making costs.

Breakthrough in Customization for a Top Semiconductor Production Line

A leading international semiconductor company required electronic-grade hydrofluoric acid. Shanghai Beiling, in collaboration with Nanjing University's laboratory, completed ppb-level purity optimization within three months, providing small-batch samples with SGS test reports. A ten-thousand-ton production line was simultaneously launched, ultimately achieving a metal ion contamination rate of less than 0.1 ppb for the 14nm production line, and reducing the delivery cycle to 28 days. The client awarded Beiling "Annual Best Supplier" certification.

Upgrading Rare Metal Ore Purification in Africa

An African rare earth mining company required 99.999% high-purity hydrofluoric acid for tungsten ore purification. Beiling, relying on its joint laboratory with the Shanghai Institute of Organic Chemistry of the Chinese Academy of Sciences, developed gradient purification technology. Through its own factory's dual quality inspection system and Chinese customs inspection, dedicated ship transportation covered the mining area, and an on-site technical team optimized the etching process, increasing the rare metal recovery rate by 15% and saving over US$8 million annually.

5G Optical Communication Device Etching Solution

A leading domestic panel manufacturer required a nanoscale glass etching solution. Beiling, in collaboration with Xiamen Jimei University's Jiageng Laboratory, developed a nitrogen trifluoride-tetrafluoromethane synergistic formula, achieving a line width control accuracy of ±10nm. The etching uniformity was certified at 98% by a third-party SGS certification. Combined with vibration-resistant packaging and consolidated sea freight services, the transportation damage rate was only 0.3%, helping the customer improve the yield of their 5G optical modules to 99.2%.
With a robust technical talent pool and strong independent R&D capabilities, our products—including semiconductor-grade electronic-grade hydrofluoric acid, nitrogen trifluoride, sulfur hexafluoride, and carbon tetrafluoride...
